Prefabricated villa glass window door luxury light steel villa

Prefabricated villa glass window door luxury light steel villa

Prefabricated villa glass window door luxury light steel villa sets a new standard for high-end residential and commercial spaces. As an innovator in prefabricated construction, we specialize in providing integrated solutions for high-end residences, commercial complexes, and unique cultural and tourism projects.

I. Core Product Advantages: Materials, Parameters, and Differentiated Design

Main Structure and Materials

Utilizing Q355B high-strength steel, the villa complies with GB/T 700-2006 standards, boasts a tensile strength of ≥375 MPa. Galvanized for corrosion resistance of over 30 years, the villa's walls feature a double-layer 140mm light steel frame, infilled with graphite polystyrene insulation board (thermal conductivity ≤ 0.032 W/(m·K)), and coated with a water-coated sand-coated finish, ensuring both aesthetics and durability. The floor system utilizes an 89mm truss beam structure with a load capacity of 350 kg/m2. Tested by the China Academy of Building Research, the structure meets the standards for earthquake resistance of magnitude 8 and wind resistance of magnitude 12.

Glass Window and Door System

Exterior windows utilize triple-glazed, dual-chamber Low-E glass (U-value ≤ 1.2 W/(m²·K)) with thermally insulated aluminum alloy frames (thermal conductivity ≤ 1.8 W/(m²·K)). These windows pass the GB/T8484-2002 thermal insulation performance test. The door system utilizes tempered laminated glass (impact strength ≥ 100J) and features concealed hinges and multi-point locks. Airtightness meets GB/T7106-2008 Level 8, and watertightness meets ≥ 700Pa of water pressure.

Luxury Customization

Spacious Flexibility: The building supports 18 modular configurations, including L-shaped and rounded shapes, with a maximum single-story area of 800 square meters. Interior partitions utilize E0-grade formaldehyde-free decorative panels for immediate move-in ready operation.

Eco-integration: Optional solar photovoltaic panels (280W/m²), a ground-source heat pump system, and intelligent fresh air ventilation reduce operating energy consumption by 40%. Artistic Exterior: Six exterior finishes are available, including fluorocarbon-coated aluminum and wood-grain metal panels. Combined with an Eiffel Tower-inspired dome design, the building creates a landmark architectural aesthetic.

II. Customized Service Process: Full-Lifecycle Management from Request to Implementation

Requirement Communication and Solution Design

A 3D visualization configuration tool is provided, allowing customers to online adjust functional areas (such as a raised living room or a hidden wine cellar), select materials (champagne gold brushed aluminum or dark gray fluorocarbon paint), and special features (cantilevered viewing platforms or sunken courtyards). Our professional team produces a design within 48 hours, integrating BIM modeling to achieve millimeter-level accuracy.

Production and Logistics

Utilizing an intelligent production line, component machining accuracy reaches ±2mm. The production cycle is 25 days for standard modules and 35 days for custom modules. We support sea and land transport, offer reinforced transportation solutions for extra-wide components, and provide door-to-door delivery worldwide, with a breakage rate of less than 0.2%. Installation and Acceptance

Our professional team completes module assembly within 72 hours and provides a welding quality inspection report (compliant with AWS D1.1 standards) and coating thickness test records (≥80μm). 32 quality inspections are completed before delivery, including load testing, airtightness testing, and optical performance verification.

III. Corporate Strength: Certifications, Case Studies, and After-Sales Guarantee

Qualification Certifications

Awarded the China Steel Structure Gold Award, the EU CE certification, and the US UL 752 safety rating. The product is ISO 9001 quality management system certified and complies with T/CCMSA 20108-2019 standards, achieving energy-saving performance of A++ grade as specified in GB/T29734.

Recommended Case Studies

Shilin Two-Story Light Steel Villa: Completed in 21 days, the villa utilizes solid cast polystyrene granules for the walls and exterior steel mesh installation, earning it the title of "Prefabricated Building Demonstration Project in Yunnan Province."

Moganshan B&B Cluster: The 12 villas feature a floating roof design and intelligent dimming glass, achieving a peak season occupancy rate of 98%, earning it the title of "China's Most Beautiful B&B." The villas supporting the Boao Forum in Hainan feature a typhoon-resistant structural system, proven to withstand force 14 winds and awarded the Hainan Province Science and Technology Progress First Prize.

After-Sales Service

We offer a 50-year structural warranty, a 10-year equipment warranty, and 24-hour global fault response. We regularly provide maintenance guidelines (such as coating inspection intervals and photovoltaic panel cleaning frequency) to extend the product lifespan to over 50 years.

IV. Business Cooperation Policy: Transparent, Flexible, and Cost-Effective

Packaging and Logistics

Components are secured with steel strapping and internally coated with EPE cushioning film, resulting in a sea freight breakage rate of less than 0.3%. We provide temporary storage services for components at our warehouse, with 60 days of free storage fees.

Minimum Order Quantity and Pricing

We provide third-party testing reports (such as SGS energy-saving ratings and simulated vibration test data from the China Earthquake Administration). Customers can schedule factory and model room visits to verify product performance.

Why Choose Us

Shijiazhuang Eiffel Steel Structure Co., Ltd.

Shijiazhuang Eiffel Steel Structure Co., Ltd. is an enterprise dedicated to researching and developing new energy-saving and environmentally friendly houses and construction methods. We always adhere to the values of honesty and quality first, and position ourselves as a leader in high-quality steel structure villa construction. We combine emerging foreign technologies with the actual domestic market and provide customers with one-stop services for prefabricated buildings such as design, production, interior decoration, and whole house customization. The prefabricated buildings produced by the company are widely used in office buildings, villas, rural courtyards, estate clubs, tourist attractions, homestays, hotels, public facilities, etc.

At present, the company is centered in Shijiazhuang, Hebei Province, with products radiating to regions such as Beijing, Tianjin, Hebei, Shanxi, Shandong, Henan, Liaoning, Mongolia, Jiangsu, Sichuan, and Guangxi, and exported to overseas markets. Adhering to the quality demand of "building a century old villa, choose Eiffel", we strive to create an excellent brand of prefabricated buildings.

House building process

Helping customers maximise value with consistent excellence
