Simple light steel villa luxury prefabricated house modular house

Simple light steel villa luxury prefabricated house modular house

The Simple Light Steel Villa Luxury Prefabricated House Modular House reimagines diverse living scenarios with an industrial aesthetic. As an innovator in prefabricated construction, we specialize in providing turnkey, full-scenario solutions for homes, cultural and tourism projects, and commercial spaces.

I. Core Advantages: Combining Easy Installation with Luxurious Features

Structural System and Materials

The main structure is constructed of Q235B high-strength steel, meeting GB/T 700-2006 standards and boasting a tensile strength of 375-500 MPa. Hot-dip galvanizing (zinc coating ≥ 80μm) provides corrosion resistance of over 15 years. The wall system consists of a double-layer 80mm light steel frame, infilled with 50mm rock wool panels (thermal conductivity ≤ 0.045 W/(m·K)), and clad with either carved metal panels or wood-grain cement cladding, offering both aesthetics and durability. The floor system utilizes an 89mm truss beam structure with a load capacity of 250kg/㎡. Tested by the China Academy of Building Research, it meets the standards for earthquake resistance of magnitude 8 and wind resistance of magnitude 10.

Simple and Rapid Deployment

Using bolted connection technology, on-site installation speeds reach 150㎡/day, shortening the construction period by 60% compared to traditional construction. For example, a Shenzhen affordable housing project, utilizing modular integration technology, completed the top-out of a 30-story building in just 148 days, shaving 14 months off the traditional construction schedule.

Luxury Features and Eco-Friendly Integration

Delivered fully furnished: Interiors utilize E0-grade environmentally friendly panels, equipped with a smart home system (integrated lighting, temperature control, and security), kitchens feature built-in appliances from Bosch, and bathrooms feature Kohler bathroom fixtures.

Renewable Energy: Optional solar photovoltaic panels (280W/㎡) and air-source heat pumps reduce operating energy consumption by 30%.

Cost Control: Unit prices start as low as 980 yuan/㎡ (including basic finishing), saving 30% of the budget compared to traditional brick-concrete structures.

II. Customized Service Process: Full-Life Cycle Management from Demand to Implementation

Demand Communication and Solution Design

A 3D visualization configuration tool is provided, allowing customers to online adjust functional zoning (e.g., standard rooms, suites, public areas), select materials (fluorocarbon sprayed aluminum panels/dark gray fluorocarbon paint), and special features (cantilevered viewing platforms, sunken courtyards). A professional team will provide a design proposal within 48 hours, integrating BIM modeling to achieve millimeter-level accuracy.

Production and Logistics

Utilizing an intelligent production line, component machining accuracy reaches ±3mm. The production cycle is 15 days for standard modules and 20 days for custom modules. We support sea and land transport, offer reinforced transportation solutions for extra-wide components, and provide door-to-door delivery worldwide, with a breakage rate of less than 0.5%.

Installation and Acceptance

A professional team completes module assembly within 48 hours and provides a welding quality inspection report (compliant with AWS D1.1 standards) and coating thickness test records (≥60μm). 24 quality inspections are completed before delivery, including load testing, airtightness testing, and optical performance verification.

III. Corporate Strength: Certifications, Case Studies, and After-Sales Guarantee

Qualifications and Certifications

Awarded the China Steel Structure Gold Award, the EU CE certification (through ETA technical evaluation), and the US UL 752 safety rating. Products are ISO 9001 quality management system certified and comply with T/CCMSA 20108-2019 standards, achieving Class A energy-saving performance as specified in GB/T29734.

References

Light Steel Villa in Tang County, Baoding, Hebei: A 135-square-meter Chinese country-style residence with a main structure cost of 350,000 yuan. It utilizes OSB (European Pine Board) and glass wool composite walls. Construction took 28 days, 50% less than traditional brick-concrete structures.

Shenzhen Anju Jingxinyuan Project: A 30-story modular high-rise building with 696 affordable housing units completed in just 148 days from hoisting to topping out. Awarded the title of "National Concrete Modular Building Demonstration Project."

Yunnan Fuxian Lake Ecological Camp: 15 container homes with integrated rainwater recycling systems save 1,200 tons of water annually. Awarded the title of "Yunnan Province Green Tourism Demonstration Project." After-Sales Service

We offer a 20-year structural warranty, a 5-year equipment warranty, and a 72-hour global fault response. We regularly provide maintenance guidelines (such as coating inspection intervals and panel cleaning frequency) to extend the product lifespan to over 30 years.

IV. Business Cooperation Policy: Transparent, Flexible, and Cost-Effective

Packaging and Logistics

Components are secured with steel strapping and internally protected with EPE cushioning film, resulting in a sea freight breakage rate of less than 0.3%. We provide temporary storage for components at our warehouse, with 60 days of free storage fees.

Minimum Order Quantity and Pricing

Performance Verification

Third-party testing reports (such as SGS energy-saving ratings and simulated vibration test data from the China Earthquake Administration) are available. Customers can schedule factory and model room visits to verify product performance.

Why Choose Us

Shijiazhuang Eiffel Steel Structure Co., Ltd.

Shijiazhuang Eiffel Steel Structure Co., Ltd. is an enterprise dedicated to researching and developing new energy-saving and environmentally friendly houses and construction methods. We always adhere to the values of honesty and quality first, and position ourselves as a leader in high-quality steel structure villa construction. We combine emerging foreign technologies with the actual domestic market and provide customers with one-stop services for prefabricated buildings such as design, production, interior decoration, and whole house customization. The prefabricated buildings produced by the company are widely used in office buildings, villas, rural courtyards, estate clubs, tourist attractions, homestays, hotels, public facilities, etc.

At present, the company is centered in Shijiazhuang, Hebei Province, with products radiating to regions such as Beijing, Tianjin, Hebei, Shanxi, Shandong, Henan, Liaoning, Mongolia, Jiangsu, Sichuan, and Guangxi, and exported to overseas markets. Adhering to the quality demand of "building a century old villa, choose Eiffel", we strive to create an excellent brand of prefabricated buildings.
